JS-300M is upgraded based on JS-300, and they are specially designed for water mist plasma cutting.
With water mist plasma cutting, the cutting smoke and noise can be obviously reduced, the cutting quality can be dramatically improved and the working parts color will not be changed after cutting, this is especially good for high quality cutting job of stainless steel, aluminum materials etc.
Technical Parameters：
Rated Input Voltage | V | 3x380(50Hz) +/- 10% |
Rated Input Power | KVA | 57 |
Cutting Current | A | 300 |
Duty Circle | - | 100% |
Cutting Thickness | mm | 40 |
Pierce Thickness | mm | 30 |
Quality Cutting | mm | 35 |
Max. Cutting | mm | 60 |
Working Gas | - | Air/N2 |
Gas Volume | L/min | 150 |
Working Gas Pressure | MPa | 0.4 |
Cooling Method | - | Water Cooling |
Weight of Machine | kg | 130 |
Size of Machine | cm | 83x47x90 |
Cutting Parameter：
Cutting Material | Cutting Thickness (mm) | Pierce Height (mm) | Cutting Height (mm) | Cutting Current (A) | Cutting Speed (mm/min) |
Carbon steel | 10 | 7 | 5 | 200 | 2100 |
Carbon steel | 20 | 8 | 6 | 300 | 1350 |
Carbon steel | 30 | 9 | 6 | 300 | 900 |
Carbon steel | 35 | 10 | 6 | 300 | 750 |
Carbon steel | 40 | 11 | 6 | 300 | 400 |
Carbon steel | 45 | Edge Cutting | 6 | 300 | 300 |
Stainless steel | 20 | 8 | 6 | 300 | 1150 |
Stainless steel | 32 | 10 | 6 | 300 | 450 |
