JS-130N series are high quality air cooling plasma power sources for CNC cutting which have high pierce capability and can achieve high verticality.
JS-130N series adopt the full-bridge soft-switching technology, current can be adjustable between 35A-130A steplessly, it can make cutting operation more controllable. It is heavy duty, 100% duty circle, and it has built in multi protections for over current, over voltage, over air-pressure, over temperature etc, allows you to work 24 hours continuously.
Technical Parameters:
Rated Input Voltage | V |
|
Rated Input Power | KVA | 18.7 |
Cutting Current | A | 35-130 |
Duty Circle | - | 130A/100% |
Cutting Thickness | mm | According to Material. |
Pierce Thickness | mm |
|
Quality Cutting | mm | 30 |
Max. Cutting | mm | 45 |
Working Gas | - | Air |
Gas Volume | L/min | 200 |
Working Gas Pressure | MPa |
|
Cooling Method | - | Air Cooling |
Weight of Machine | kg | 60 |
Size of Machine | cm | 68x35x63 |
Cutting Parameter:
Cutting Material | Cutting Thickness (mm) | Pierce Height (mm) | Cutting Height (mm) | Cutting Current (A) | Cutting Speed (mm/min) |
Carbon Steel | 3 | 4 | 3 | 60 | 3600 |
Carbon Steel | 20 | 7 | 5 | 130 | 850 |
Carbon Steel | 25 | Edge Cutting | 5 | 130 | 600 |
Stainless Steel | 3 | 4 | 3 | 60 | 2000 |
Stainless Steel | 18 | 7 | 5 | 130 | 750 |
Stainless Steel | 20 | Edge Cutting | 5 | 130 | 680 |
Aluminum | 3 | 4 | 3 | 60 | 2550 |
Aluminum | 18 | 7 | 5 | 130 | 900 |
Aluminum | 20 | Edge Cutting | 5 | 130 | 780 |
